تونجر شحن 45 امبير موديل TELWIN ALPINE 50

شاحن بطارية 45 أمبير 12-24 فولت TELWIN موديل ALPINE 50

ALPINE 50 BOOST
Telwin SPA – Via della Tecnica, 3 36030 Villaverla (VI) – ITALY
www.telwin.com
ALPINE 50 BOOST – PAG. 1/2
Battery charger for WET 12/24V batteries. With ammeter and normal or fast (BOOST) charge selector. 1000W.
Protection against overcharging and pole inversion.
Telwin SPA – Via della Tecnica, 3 36030 Villaverla (VI) – ITALY
www.telwin.com
ALPINE 50 BOOST – PAG. 2/2
TECHNICAL DATA
CODE 807548 CHARGING VOLTAGE 12 / 24 V MAX.RATED REFERENCE CAPAC. 500 Ah
SINGLEPHASE MAINS VOLTAGE 230 V EFFICIENT CHARGING CURRENT 45 A ADJUSTMENT POSITIONS 4
MAINS FREQUENCY 50 / 60 Hz RATED CHAR.CUR.EN60335-2-29 31 A DIMENSIONS (LxWxH) 26,5 x 34,5 x 23 cm
CHARGING ABSORBED POWER 1000 W MIN.RATED REFERENCE CAPAC. 20 Ah WEIGHT 9,9 kg
SUPPLIED ACCESSORIES
123569 CABLE 6 MMQ 2 M AND WORK CLAMP
123581 CABLE 6MMQ 2 M POSITIVE CLAMP
OPTIONAL ACCESSORIES
BATTERY CHARGERS FUSES
802259 FUSES 50A 20 PCS
DESCRIPTION
Battery charger for charging free electrolyte batteries (WET) with 12V/24V voltage.
Protected againstoverloads and polarity reversal.
Equipped with selector for normal or quick (BOOST) charge. Equippedwith ammeter.
DOWNLOAD
CATALOG IMAGE INSTRUCTION MANUAL SPARE PARTS LIST
CERTIFICATE
